EW1N/EW1S/EW1M/ Ø90/Ø125/Ø160 Single Head Wall Light
The SLANA series is more decorative in architectural lighting. It is wall mounted, with unidirectional light distribution, exquisite&detailed appearance and structural design, excellent optical performance and flexible&user-friendly accessories can bring users a perfect light environment experience and are suitable for functional lighting in public high spaces.
| Model | Comment | Power (W) | LEDs (Quantity) | Max Lumens (lm) | Control Systems | Beam | CCT | Finish |
EW1N | S Single Directional | 16 13(Max) | COB | 1172 | EL ON-OFF 220V AC Power Supply DL 0-10V Dimming 220V AC Power Supply | 1 14° 2 25° 3 35° A Away from the wall T Towards the wall | 30 3000K 40 4000K | WT White BK Black |
| Model | Comment | Power (W) | LEDs (Quantity) | Max Lumens (lm) | Control Systems | Beam | CCT | Finish |
EW1S | S Single Directional | 27 25(Max) | COB | 2251 | EL ON-OFF 220V/AC Power Supply DL 0-10V Dimming 220V/AC Power Supply | 1 16° 2 21° 3 33° A Away from the wall T Towards the wall | 30 3000K 40 4000K | WT White BK Black |
| Model | Comment | Power (W) | LEDs (Quantity) | Max Lumens (lm) | Control Systems | Beam | CCT | Finish |
EW1M | S Single Directional | 36 32(Max) | COB | 2783 | EL ON-OFF 220V/AC Power Supply DL 0-10V Dimming 220V/AC Power Supply | 1 16 2 30° 4 40° A Away from the wall T Towards the wall | 30 3000K 40 4000K | WT White BK Black |
Example: EW1MS-36EL-130WT
